| Nombor Bahagian : | EEU-FC1H222C |
|---|---|
| Pengilang / jenama : | Panasonic |
| Penerangan : | CAP ALUM 2200UF 20% 50V RADIAL |
| Status RoHS : | Lead percuma / RoHS Compliant |
| Kuantiti Tersedia | 33959 pcs |
| Helaian data | EEU-FC1H222C.pdf |
| Voltan - Rated | 50V |
| Toleransi | ±20% |
| Permukaan Gunung Land Saiz | - |
| Saiz / Dimensi | 0.709" Dia (18.00mm) |
| Siri | FC |
| Ripple Current @ Low Frequency | 2.48A @ 120Hz |
| penilaian | AEC-Q200 |
| polarisasi | Polar |
| pembungkusan | Bulk |
| Pakej / Kes | Radial, Can |
| Nama lain | EEU-FC1H222C-ND EEUFC1H222C P19488 |
| Suhu Operasi | -55°C ~ 105°C |
| pemasangan Jenis | Through Hole |
| Tahap Sensitiviti Lembapan (MSL) | 1 (Unlimited) |
| Pengilang Standard Lead Time | 15 Weeks |
| Sepanjang Hayat @ Temp. | 5000 Hrs @ 105°C |
| Lead Jarak | - |
| Status Status Percuma / Rosh Status | Lead free / RoHS Compliant |
| galangan | 23 mOhms |
| Tinggi - Duduk (Max) | 1.476" (37.50mm) |
| ESR (Siri rintangan Setaraf) | - |
| Penerangan terperinci | 2200µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C |
| kemuatan | 2200µF |
| aplikasi | Automotive |
Panasonic
