| Nombor Bahagian : | EEE-FT1E330AR |
|---|---|
| Pengilang / jenama : | Panasonic |
| Penerangan : | CAP ALUM 33UF 20% 25V SMD |
| Status RoHS : | Lead percuma / RoHS Compliant |
| Kuantiti Tersedia | 437064 pcs |
| Helaian data | 1.EEE-FT1E330AR.pdf2.EEE-FT1E330AR.pdf3.EEE-FT1E330AR.pdf4.EEE-FT1E330AR.pdf5.EEE-FT1E330AR.pdf |
| Voltan - Rated | 25V |
| Toleransi | ±20% |
| Permukaan Gunung Land Saiz | 0.169" L x 0.169" W (4.30mm x 4.30mm) |
| Saiz / Dimensi | 0.157" Dia (4.00mm) |
| Siri | FT |
| Ripple Current @ Low Frequency | 104mA @ 120Hz |
| Ripple Current @ High Frequency | 160mA @ 100kHz |
| penilaian | AEC-Q200 |
| polarisasi | Polar |
| pembungkusan | Tape & Reel (TR) |
| Pakej / Kes | Radial, Can - SMD |
| Nama lain | EEEFT1E330AR PCE5004TR |
| Suhu Operasi | -55°C ~ 105°C |
| pemasangan Jenis | Surface Mount |
| Tahap Sensitiviti Lembapan (MSL) | 1 (Unlimited) |
| Pengilang Standard Lead Time | 19 Weeks |
| Sepanjang Hayat @ Temp. | 2000 Hrs @ 105°C |
| Lead Jarak | - |
| Status Status Percuma / Rosh Status | Lead free / RoHS Compliant |
| Tinggi - Duduk (Max) | 0.240" (6.10mm) |
| ESR (Siri rintangan Setaraf) | 850 mOhm @ 100kHz |
| Penerangan terperinci | 33µF 25V Aluminum Electrolytic Capacitors Radial, Can - SMD 850 mOhm @ 100kHz 2000 Hrs @ 105°C |
| kemuatan | 33µF |
| aplikasi | Automotive |
Panasonic
